U-shaped silicon carbide rod

Name: Ushaped silicon carbide rod
Brand: SONGYU
Price: 1 USD

MOQ : 10pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 10-1000pcs

Delivery Time : 15 work days

Packaging Details : WOODEN CASE

Material : Silicon carbide

Power : Customizable

Mounting Type : Horizontal or vertical

Heating Element Type : Silicon carbide

Thermocouple Position : Customizable

Diameter : Customizable

Heating Zone : Single or multiple

Maximum Temperature : Customizable

Terminal Connection : Threaded or flanged

Shape : U-shaped

Length : Customizable

Thermocouple Type : K or J type

Insulation Material : Mullite or alumina

Voltage : Customizable

Place of Origin : China

Brand Name : SONGYU

Contact Now

U-shaped silicon carbide rod

The U-shaped silicon heating element is made by taking two carefully matched SiC rods and welding a thick silicon carbide bridge. The U-shaped component connects the two ends from one side of the furnace. The tail end of the cold end is made of aluminum metal, providing a low resistance contact surface for the aluminum connecting strip and fixture.

Features:

1. High strength and excellent shock resistance;

2. Heat source is free of noise and air pollution;

3. Anti-oxidization;

4. Anti-corrosion,

5. Long service life,

6. Little deformation,

7. Easy installation and maintenance.

8. Excellent specific rate of heat zone resistance and cold end resistance,

9. Avoiding over-temperature of cold ends to damage the furnace body.

10. Saving energy

Outer Diameter (OD, mm)	Hot zone (HZ, mm)	Cold zone (CZ, mm)	Overall length (OL, mm)	Range of resistance (ohms)
8	100-300	60-200	240-700	2.1-8.6
14	100-500	150-350	400-1200	0.7-5.6
16	200-600	200-350	600-1300	0.7-4.4
18	200-800	200-400	600-1600	0.7-5.8
20	200-800	250-600	700-2000	0.6-6.0
25	200-1200	250-700	700-2600	0.4-5.0
30	300-2000	250-800	800-3600	0.4-4.0
35	400-2000	250-800	900-3600	0.5-3.6
40	500-2700	250-800	1000-4300	0.5-3.4
45	500-3000	250-750	1000-4500	0.3-3.0
50	600-2500	300-750	1200-4000	0.3-2.5
54	600-2500	300-750	1200-4000	0.3-3.0

Product Tags:

customizable silicon carbide rod

customizable silicon carbide element

Wholesale U-shaped silicon carbide rod from china suppliers

U-shaped silicon carbide rod Images
